Send InquirySurge arrester for low-voltage power supplies Visual fault signalling for DP-012/24/48/60
Product Details:
- Product Type Surge arrester for low-voltage power supplies Visual fault signalling for DP-012/24/48/60
- Application Industrial
- Frequency (MHz) 50 Hertz (HZ)
- Color Gray
Surge arrester for low-voltage power supplies Visual fault signalling for DP-012/24/48/60 Price And Quantity
- 2000 INR/Piece
- 20 Piece
Surge arrester for low-voltage power supplies Visual fault signalling for DP-012/24/48/60 Product Specifications
- Gray
- Surge arrester for low-voltage power supplies Visual fault signalling for DP-012/24/48/60
- 50 Hertz (HZ)
- Industrial
Product Description
Surge Arresters
DP012
DP024
DP048
DP060
Surge arrester for lowvoltage power supplies Visual fault signalling Designed to protect a line of equipment connected to distributions of DC and AC supply voltage According to the concept of lightning protection zones it is installed at the boundary of LPZ 1LPZ 2 zones and higher
Technical data
DP012
DP024
DP048
DP060
Location SPD
ST 2
ST 2
ST 2
ST 2
Nominal voltage Un
12 V ACDC
24 V ACDC
48 V ACDC
60 V ACDC
Maximum operating voltage Uc
28 V DC 22 V AC
44 V DC 34 V AC
90 V DC 70 V AC
90 V DC 70 V AC
Nominal current IL
16 A
16 A
16 A
16 A
C2 nominal discharge current 820 s per line In
2 kA
2 kA
2 kA
2 kA
C2 voltage protection level line line at In UP
160 V
200 V
360 V
390 V
C2 voltage protection level line PE at In Up
530 V
530 V
550 V
550 V
C3 voltage protection level line line at 1 kVs In
2 kA 2 kA
2 kA 2 kA
2 kA 2 kA
2 kA 2 kA
C3 voltage protection level line PE at 1 kVs Uoc
4 kV 4 kV
4 kV 4 kV
4 kV 4 kV
4 kV 4 kV
voltage protection level a1b1 a1 b1 PE Up
160 V 530 V
200 V 530 V
360 V 550 V
390 V 550 V
Maximum current protection
16 A gLgG or C 16 A
16 A gLgG or C 16 A
16 A gLgG or C 16 A
16 A gLgG or C 16 A
Response time line line ta
25 ns
25 ns
25 ns
25 ns
Response time line PE ta
100 ns
100 ns
100 ns
100 ns
Degree of protection
IP 20
IP 20
IP 20
IP 20
Range of operating temperatures
40 C 80 C
40 C 80 C
40 C 80 C
40 C 80 C
Mounting on
Crosssection of connected conductors
Solid max
ISO 4 mm2 AWG 11
ISO 4 mm2 AWG 11
ISO 4 mm2 AWG 11
ISO 4 mm2 AWG 11
Stranded max
ISO 25 mm2 AWG 13
ISO 25 mm2 AWG 13
ISO 25 mm2 AWG 13
ISO 25 mm2 AWG 13
Tightening torque
06 Nm
06 Nm
06 Nm
06 Nm
Fault indication
red indicator
red indicator
red indicator
red indicator
Meets the requirements of standard
EN 6164321
EN 6164311 A11T3
EN 6164321
EN 6164311 A11T3
EN 6164321
EN 6164311 A11T3
EN 6164321
EN 6164311 A11T3
Ordering number
8595090521877
8595090516040
8595090521884
8595090521907
