Lightning current arrester for coaxial line quarter-wave short circuit

Product Description

Lightning current arresters

ZX24 N50SMA

ZX5 N50SMA

Lightning current arrester for coaxial line quarterwave short circuit Designed to protect coaxial lines and telecommunication

equipment It is installed at the boundary of LPZ 0A and LPZ 1 zones and higher at the line entry into the building

It is unsuitable for combined signal distributions and supply voltage

Technical data

ZXxx N50SMA

Location SPD

ST 123

D1 lightning impulse current 10350 s line  PE I imp

15 kA

C2 nominal discharge current 820 s line  PE In

20 kA

Voltage protection level line  PE at 1 kVs C3 up

25 V

Wave impedance Z

50

Insertion attenuation

 12 dB

SWR

15

Degree of protection

IP 20

Range of operating temperatures

 40 C   80 C

Connection input  output

female N50SMA

Cable length L

250 mm

SWR

 12

Meets the requirements of standard

EN 6164321

type

Frequency

ZX24 N50SMA

2226 GHz

ZX5 N50SMA

558 GHz
