Send InquiryDIGITAL LIGHTNING COUNTER
Product Details:
- Product Type Lightning Counter
- Application Industrial/Residential
- Frequency (MHz) 50 Hertz (HZ)
- Color White/Grey
- Dimension (L*W*H) 4x3x2 Apprx. Inch (in)
- Warranty 1 year
12000 INR/Piece
X
DIGITAL LIGHTNING COUNTER Price And Quantity
- 5 Piece
- 12000 INR/Piece
DIGITAL LIGHTNING COUNTER Product Specifications
- 4x3x2 Apprx. Inch (in)
- White/Grey
- Industrial/Residential
- Lightning Counter
- 1 year
- 50 Hertz (HZ)
DIGITAL LIGHTNING COUNTER Trade Information
- Lucknow
- 1000 Piece Per Month
- 1-3 Days
- No
- Sample costs shipping and taxes has to be paid by the buyer
- Carton
- Australia North America South America Eastern Europe Western Europe Middle East Africa Central America Asia
- All India
- ISO 9001:2015, OHSAS 18001:2007, CE, IEC 62561-6:2011
Product Description
SDLC6 Lightning Strike Counter Digital 6 digits IP65Product Manual1 IntroductionSDLC6 waterproof lightning counter is an universal type lightning counter When the lightning protection circuit system is normal there is no lightning current in the discharge line the lightning counter dont count When the lightning current is discharged to the ground the lightning counter can induce it and counts correctlySDLC6 waterproof lightning strike counter is suitable for all SPD lightning rod etc It can induce the discharge current and count and then display the number of lightning strike in the screen This Lightning Counter can count accurately If power failure the operational data wont lose It takes the advantages of dustproof and waterproof etc
2 Technical Parameter Type Waterproof Lightning Strike Counter Minimum Counting Current820 s 500ACount Number 0999999 times Down Conductor Maximum Diameter D 25mmMeasure LWH 100 x 68 x 70mm Working Humidity 95Operating Temperature 40 850C
3 Installation Instruction
1 SDLC6 waterproof lightning counter can be installed at the ground wire of power SPD or the down conductor bare part of lightning rod The installation diagram is as follow
2 Loosen the two screw nuts in the back of lightning counter spring washer and flat gasket remove the clamp to put the ground wire of power SPD and or the down conductor bareness part of lightning rod between the two screw nuts and then put the pressing plate flat gasket spring washer screw nuts tighten the two screw nuts
3 Pay attention to ground wire of power SPD or the down conductor of lightning rod Installation and wiring diagram bareness part of lightning rod and the mounting platepressing plate The contact segment must be well connected to low down the contact resistance to make sure the counting accuracy
4 MaintenanceSDLC6 waterproof lightning counter doesnt need special maintenance Annually to check the ground wire of power SPD or the down conductor bareness part of lightning rod to see whether the contact segment is well connected or not
